fiber optics

fiber optics transmission of digitized messages or information by light pulses along hair-thin glass fibers. Each fiber is surrounded by a cladding having a high index of refractance so that the light is internally reflected and travels the length of the fiber without escaping. Cables of optical fibers can be made smaller and lighter than conventional cables using copper wires or coaxial tubes, yet they can carry much more information, making them useful for transmitting large amounts of data between computers and for carrying data-intensive television pictures or many simultaneous phone conversations. Optical fibers are immune to electromagnetic interference (from lightning, nearby electric motors, and similar sources) and to crosstalk from adjoining wires, and tapping into them is more easily detected. To keep a signal from deteriorating, optical fibers require fewer repeaters over a given distance than does copper wire. In addition to communications, optical fibers are beginning to be used in medical procedures, automobiles, and aircraft and are expected to have many other applications.

fi·ber op·tics • pl. n. [treated as sing.] the use of thin flexible fibers of glass or other transparent solids to transmit light signals, chiefly for telecommunications or for internal examination of the body. ∎  [treated as pl.] the fibers and associated devices so used. DERIVATIVES: fi·ber-op·tic adj.

fiber optics A means of transmitting analog or digital information using light signals over an optical fiber. An optical fiber is a thin transparent filament made either of glass or, for short distances, special plastics; the diameter of the fiber ranges downward from 125 micrometers, with a number of preferred sizes now being adopted as standard. The information is carried as a light signal, typically in the infrared with a wavelength of about 1200 to 1550 nanometers, and generated by an electrical-to-optical transducer, usually a switchable semiconductor laser. Light of wavelength 1200 nm has a frequency of 250 000 gigahertz (GHz), and is in principle capable of transmitting at bit rates of the order of 100 000 Gbps. The highest bit rates achieved in the laboratory are of the order of 1000 Gbps, and the highest rates in normal use are of the order of a few hundred Mbps, the limits being set by the speeds at which the semiconductor lasers and the optical-to-electrical transducers can operate.

A variety of methods are used to reduce the loss of the optical signal and hence increase signaling distance. The material of which the fiber is made is very pure, and by varying the refractive index of the material across the fiber it is possible to cause light rays at less than a certain angle to the axis of the fiber to be totally internally reflected back into the fiber. This reflection may take place at a discrete boundary between glasses of different refractive index (stepped index fiber), or may take place in a region of gradually varying refractive index (graded index fiber). If the fiber is made very thin, with a diameter of the order of the wavelength of the light, the light rays can only propagate along the fiber (monomode fiber). On a very long path, it is necessary to install amplifiers to regenerate the signal – by converting it from an optical to an electrical form, amplifying the electrical signal, and then reconverting it to an optical signal. Some amplifier designs exploit the nonlinear optical properties of certain glasses to allow direct amplification of the optical signal using a locally powered second laser as the power source.
