electric battery device that converts chemical energy into electrical energy, consisting of a group of electric cells that are connected to act as a source of direct current. The term is also now commonly used for a single cell, such as the alkaline dry cell used in flashlights and portable tape players, but strictly speaking batteries are made up of connected cells encased in a container and fitted with terminals to provide a source of direct electric current at a given voltage. A cell consists of two dissimilar substances, a positive electrode and a negative electrode, that conduct electricity, and a third substance, an electrolyte, that acts chemically on the electrodes. The two electrodes are connected by an external circuit (e.g., a piece of copper wire); the electrolyte functions as an ionic conductor for the transfer of the electrons between the electrodes. The voltage, or electromotive force, depends on the chemical properties of the substances used, but is not affected by the size of the electrodes or the amount of electrolyte.

Batteries are classed as either dry cell or wet cell. In a dry cell the electrolyte is absorbed in a porous medium, or is otherwise restrained from flowing. In a wet cell the electrolyte is in liquid form and free to flow and move. Batteries also can be generally divided into two main types—rechargeable and nonrechargeable, or disposable. Disposable batteries, also called primary cells, can be used until the chemical changes that induce the electrical current supply are complete, at which point the battery is discarded. Disposible batteries are most commonly used in smaller, portable devices that are only used intermittently or at a large distance from an alternative power source or have a low current drain. Rechargeable batteries, also called secondary cells, can be reused after being drained. This is done by applying an external electrical current, which causes the chemical changes that occur in use to be reversed. The external devices that supply the appropriate current are called chargers or rechargers.

A battery called the storage battery is generally of the wet-cell type; i.e., it uses a liquid electrolyte and can be recharged many times. The storage battery consists of several cells connected in series. Each cell contains a number of alternately positive and negative plates separated by the liquid electrolyte. The positive plates of the cell are connected to form the positive electrode; similarly, the negative plates form the negative electrode. In the process of charging, the cell is made to operate in reverse of its discharging operation; i.e., current is forced through the cell in the opposite direction, causing the reverse of the chemical reaction that ordinarily takes place during discharge, so that electrical energy is converted into stored chemical energy. The storage battery's greatest use has been in the automobile where it was used to start the internal-combustion engine. Improvements in battery technology have resulted in vehicles—some in commercial use—in which the battery system supplies power to electric drive motors instead.

Batteries are made of a wide variety of electrodes and electrolytes to serve a wide variety of uses. Batteries consisting of carbon-zinc dry cells connected in various ways (as well as batteries consisting of other types of dry cells) are used to power such devices as flashlights, lanterns, and pocket-sized radios and CD players. Alkaline dry cells are an efficient battery type that is both economical and reliable. In alkaline batteries, the hydrous alkaline solution is used as an electrolyte; the dry cell lasts much longer as the zinc anode corrodes less rapidly under basic conditions than under acidic conditions. In the United States the lead storage battery is commonly used. A more expensive type of lead-acid battery called a gel battery (or gel cell) contains a semisolid electrolyte to prevent spillage. More portable rechargeable batteries include several dry-cell types, which are sealed units and are therefore useful in appliances like mobile phones and laptops. Cells of this type (in order of increasing power density and cost) include nickel-cadmium (nicad or NiCd), nickel metal hydride (NiMH), and lithium-ion (Li-Ion) cells.

There is evidence that primitive batteries were used in Iraq and Egypt as early as 200 BC for electroplating and precious metal gilding. In 1748, Benjamin Franklin coined the term battery to describe an array of charged glass plates. However, most historians date the invention of batteries to about 1800 when experiments by Alessandro Volta resulted in the generation of electrical current from chemical reactions between dissimilar metals. Experiments with different combinations of metals and electrolytes continued over the next 60 years. In the 1860s, Georges Leclanche of France developed a carbon-zinc wet cell; nonrechargeable, it was rugged, manufactured easily, and had a reasonable shelf life. Also in the 1860s, Raymond Gaston Plant invented the lead-acid battery. It had a short shelf life, and about 1881 Émile Alphonse Faure developed batteries using a mixture of lead oxides for the positive plate electrolyte with faster reactions and higher efficiency. In 1900, Thomas Alva Edison developed the nickel storage battery, and in 1905 the nickel-iron battery. During World War II the mercury cell was produced. The small alkaline battery was introduced in 1949. In the 1950s the improved alkaline-manganese battery was developed. In 1954 the first solar battery or solar cell was introduced, and in 1956 the hydrogen-oxygen fuel cell was introduced. The 1960s saw the invention of the gel-type electrolyte lead-acid battery. Lithium-ion batteries, wafer thin and powering portable computers, cell phones, and space probes were introduced in the 1990s. Computer chips and sensors now help prolong battery life and speed the charging cycle. Sensors monitor the temperature inside a battery as chemical reactions during the recharging cause it to heat up; microchips control the power flow during recharging so that current flows in rapidly when the batteries are drained and then increasingly slowly as the batteries become fully charged. Another source of technical progress is nanotechnology; research indicates that batteries employing carbon nanotubes will have twice the life of traditional batteries.

See also electric circuit ; fuel cell ; solar cell .

Battery

A battery is a device for converting chemical energy into electrical energy. Batteries can consist of a single voltaic cell or a series of voltaic cells joined to each other. (In a voltaic cell, electrical energy is produced as the result of a chemical reaction between two different metals immersed in a solution, usually a liquid.) Batteries can be found everywhere in the world around us, from the giant batteries that provide electrical energy in spacecraft to the miniature batteries that power radios and penlights.

The correct use of the term battery is reserved for groups of two or more voltaic cells. The lead storage battery found in automobiles, for example, contains six voltaic cells. However, in common usage, a single cell is often referred to as a battery. For example, the common dry cell battery found in flashlights is really a single voltaic cell.

Types of batteries

Batteries can be classified as primary or secondary batteries (or cells). A primary battery is one designed to be used just once. When the battery has run down (produced all the energy it can), it is discarded. Secondary batteries, on the other hand, can be recharged and reused.

Special Kinds of Batteries

The best known example of a primary battery is probably the common dry cell invented by French engineer Georges Leclanché (1839–1882). The dry cell consists of a zinc container that supplies electrons to the battery; a carbon rod through which the electrons flow; and a moist paste of zinc chloride and ammonium chloride, which accepts the electrons produced from the zinc. Technically, the zinc container is the anode (the electrode at which electrons are given up to a reaction) and the moist paste is the cathode (the electrode at which electrons are taken up from a reaction) in the cell. The Leclanché cell is called a dry cell because no liquid is present in it. However, it is not really dry because of the presence of the moist paste, which is needed if electrons are to flow through the cell.

The dry cell runs down as the zinc can is slowly used up. At some point there is not enough zinc left to produce electrons at a useable rate. At that point, the dry cell is just thrown away.

Secondary cells. The secondary cell with which you are likely to be familiar is the lead storage battery found in automobiles. The lead storage battery usually consists of six voltaic cells connected to each other. The total amount of energy produced by the battery is equal to the sum of the electrical energy from the six cells. Since each cell produces about two volts, the total energy available from the cell is 12 volts.

As the lead storage battery is used, it runs down. That is, the lead plates in the battery are converted to lead sulfate. Unlike the dry cell, however, this process can be reversed. Electrical current can be passed back into the battery, and lead sulfate is changed back into lead. If you could see the lead plates in a battery, you would see them slowly disappearing when the battery is being used and slowly reappearing when the battery is being recharged. Recharging occurs naturally when the automobile is operating and generating its own electricity or when a source of external current is provided in order to recharge the battery.

[See also Cell, electrochemical; Electrical conductivity; Electric current; Electricity ]

bat·ter·y / ˈbatərē/ • n. (pl. -ter·ies) 1. a container consisting of one or more cells, in which chemical energy is converted into electricity and used as a source of power: [as adj.] battery power. 2. a fortified emplacement for heavy guns. 3. a set of similar units of equipment, typically when connected together: a battery of equipment to monitor blood pressure. ∎  an extensive series, sequence, or range of things: children given a battery of tests. 4. Law the crime or tort of unconsented physical contact with another person, even where the contact is not violent but merely menacing or offensive. See also assault and battery. 5. (the battery) Baseball the pitcher and the catcher in a game, considered as a unit.

battery Collection of voltaic cells that convert chemical energy into direct current (DC) electricity. The term is also commonly used for a single cell, particularly the dry, electrochemical cell used in electronic equipment. Most primary cell batteries are not rechargeable; some types of primary cell – such as nickel-cadmium (Nicad) batteries – and all accumulators (storage batteries) can be recharged when a current passed through them in the reverse direction restores the original chemical state. A battery's capacity is normally measured in ampere-hours; one ampere-hour is equal to 3600 coulombs.

BATTERY, ELECTRIC

BATTERY, ELECTRIC. SeeElectricity and Electronics .
