transformer

transformer electrical device used to transfer an alternating current or voltage from one electric circuit to another by means of electromagnetic induction . The simplest type of transformer consists of two coils of wire, electrically insulated from one another and arranged so that a change in the current in one coil (the primary) will produce a change in voltage in the other (the secondary). In many transformers the coils are wound on a core made of a material with high magnetic permeability; this intensifies the magnetic field induced by the current in the primary, increasing the transformer's efficiency. Neglecting power losses (which are made small by careful design), the ratio of primary voltage to secondary voltage is the same as the ratio of the number of turns in the primary coil to the number of turns in the secondary coil. The primary and secondary currents are in inverse proportion to the number of turns in the coils. The primary and secondary impedances are in the same ratio as the squares of the numbers of turns in the primary and secondary coils. For example, if a 10-volt, 2-ampere alternating current were to flow through a 10-turn primary of a transformer, theoretically a 20-turn secondary would exhibit a 20-volt, 1-ampere alternating current, with the output impedance four times as great as the input impedance. Transformers are frequently classified according to their uses; the details of construction depend on the intended application. Power transformers are generally used to transmit power at a constant frequency. Audio transformers are designed to operate over a wide range of frequencies with a nearly flat response, i.e., a nearly constant ratio of input to output voltage. Radio frequency (RF) transformers are designed to operate efficiently within a narrow range of high frequencies.

transformer Device for converting alternating current at one voltage to another voltage at the same frequency. It consists of two coils of wire coupled together magnetically. The input current is fed to one coil (the primary), the output being taken from the other coil (the secondary).
