refraction in physics, deflection of a wave on passing obliquely from one transparent medium into a second medium in which its speed is different, as the passage of a light ray from air into glass. Other forms of electromagnetic radiation , in addition to light waves, can be refracted, as can sound waves.

The Nature of Refraction

Refraction is commonly explained in terms of the wave theory of light and is based on the fact that light travels with greater velocity in some media than it does in others. When, for example, a ray of light traveling through air strikes the surface of a piece of glass at an oblique angle, one side of the wave front enters the glass before the other and is retarded (since light travels more slowly in glass than in air), while the other side continues to move at its original speed until it too reaches the glass. As a result, the ray bends inside the glass, i.e., the refracted ray lies in a direction closer to the normal (the perpendicular to the boundary of the media) than does the incident ray. A light ray entering a different medium is called the incident ray; after bending, the ray is called the refracted ray. The speed at which a given transparent medium transmits light waves is related to its optical density (not to be confused with mass or weight density ). In general, a ray is refracted toward the normal when it passes into a denser medium and away from the normal when it passes into a less dense medium.

The Law of Refraction

The law of refraction relates the angle of incidence (angle between the incident ray and the normal) to the angle of refraction (angle between the refracted ray and the normal). This law, credited to Willebrord Snell, states that the ratio of the sine of the angle of incidence, i, to the sine of the angle of refraction, r, is equal to the ratio of the speed of light in the original medium, v_i , to the speed of light in the refracting medium, v_r , or sin i /sin r = v_i / v_r . Snell's law is often stated in terms of the indexes of refraction of the two media rather than the speeds of light in the media. The index of refraction, n, of a transparent medium is a direct measure of its optical density and is equal to the ratio of the speed of light in a vacuum, c, to the speed of light in the medium: n = c/v.

Indexes of refraction are always equal to or greater than 1; for air, n =1.00029; for water, n =1.33. Using indexes of refraction, Snell's law takes the form sin i /sin r = n_r  / n_i , or n_i sin i = n_r sin r. If the original medium is denser than the refracting medium ( n_i greater than n_r ), sin r will be greater than sin i. Thus, there will be some acute angle less than 90° for the incident ray corresponding to an angle of refraction of 90°. This angle of incidence is known as the critical angle. For angles of incidence greater than the critical angle, refraction cannot take place and the incident ray is instead reflected back into the original medium according to the law of reflection (angle of reflection equals angle of incidence). This phenomenon is known as total internal reflection.

Applications of Refraction

Refraction has many applications in optics and technology. A lens uses refraction to form an image of an object for many different purposes, such as magnification. A prism uses refraction to form a spectrum of colors from an incident beam of light. Refraction also plays an important role in the formation of a mirage and other optical illusions.

refraction, the bending of light rays as they pass from one medium to another of different optical density, an important consideration in celestial navigation. Light from an observed celestial body or from the observer's visible horizon suffers atmospheric refraction, the former being called celestial refraction, the latter terrestrial refraction. The effect of atmospheric refraction is to elevate celestial objects and the horizon, so that it is necessary to make allowance for this effect when converting observed altitudes to true ones. The altitude correction, known as mean refraction, is defined as the angular measure along an arc of a vertical circle between the true and apparent directions of a celestial body, when atmospheric temperature, pressure, and humidity are normal. Abnormal refraction gives rise to effects such as loom and mirage. Mean refraction varies from about 33 minutes of arc for objects on the horizon to nothing for objects as the zenith.

refraction Bending of a wave, such as a light or sound wave, when it crosses the boundary between two media, such as air and glass, and undergoes a change in velocity. The incident wave (striking the surface), refracted wave and the normal (line perpendicular to the surface) all lie in the same plane. The incident wave and refracted wave make an angle of incidence, i, and an angle of refraction, r, with the normal. The index of refraction for a transparent medium is the ratio of the speed of light in a vacuum to its speed in the medium. Snell's law states that this ratio is constant for a given interface. See also reflection

refraction (ri-frak-shŏn) n. the change in direction of light rays when they pass obliquely from one transparent medium to another, of a different density. Refraction occurs as light enters the eye and passes through the cornea, lens, etc., to come to a focus on the retina. error of r. (refractive error) an abnormality of the eye, such as astigmatism or long- or short-sightedness, in which a blurred image forms on the retina due to abnormal focusing.
—refractive (ri-frak-tiv) adj.

refraction The bending of a ray which travels obliquely from one medium to another, at the interface separating the two; it is caused by the contrast in velocities with which the ray travels in the two media, and described by Snell's law. See also REFRACTION SURVEY.
