Lighting. The open-air performances in Greece, Rome, medieval Europe, and Elizabethan England—also in Spain's Golden Age—took place by daylight, with torches used for the final scenes. It was only in the enclosed private playhouses, which originated in Renaissance Italy and gradually spread across Europe, that artificial lighting was needed, and even there large windows could throw light on to the stage for afternoon performances. However, the value of artificial light in the theatre was soon apparent, particularly as an additional element in the stage picture, and as early as 1545 Serlio advised placing candles or lamps behind coloured glass in windows, or behind bottles filled with coloured liquid to give a jewel-like effect. He also advocated the use of barbers' basins behind the lamps to act as reflectors. The auditorium was at first brightly lit by lamps or candelabra. In the 1560s the Jewish dramatist Leone di Somi (1527–92), in his Dialogues on Stage Affairs, insisted on reducing the amount of light in the auditorium in order to intensify the effect of the stage lighting. He also used mirror reflectors behind lamps fixed to the backs of the side wings, and extinguished many of the stage lamps at the first tragic moment in a play, which apparently had a profound effect upon the spectators. A later writer on the theatre, Angelo Ingegneri (c.1550–c.1613), wanted to darken the auditorium entirely, but this was not achieved for a very long time, possibly because a fashionable audience wanted to be seen as well as to see. The theatres of the 17th and 18th centuries continued to use candelabra hung over the stage and auditorium, with concealed lamps behind the wings and below the backcloth, and also footlights which, as can be inferred by a reference to them in the Architectura civilis of the German architect Josef Furtenbach (1591–1667), were in use by 1628, a practice further confirmed by the Italian architect Nicola Sabbattini (1574–1654) in his book Pratica di fabricar scene e machine ne'teatri (1638). Footlights are first shown in use in an English theatre in the frontispiece to Kirkman's The Wits (1672). The unconcealed chandeliers over the stage threw a painful glare into the eyes of the spectators in the gallery, as Pepys recorded as early as 1669, and Garrick at Drury Lane in 1765, in imitation of the French theatre, was the first in England to remove them entirely, relying on extra lamps concealed behind the wings, in addition to the footlights, to give a sufficiently strong light on stage. The same improvement was made at Covent Garden, but with rather smelly oil-lamps instead of wax candles. Gas was first used to light the stage at the Lyceum in Aug. 1817. The Olympic in 1815 was possibly the first theatre to use gas inside the playhouse, but the first London theatre to be entirely given over to gas-lighting was Drury Lane in Sept. 1817. Covent Garden followed two days later. The new lighting was considered a great improvement, and in the next 10 years practically all the more important theatres in London and the provinces were converted to it, the Haymarket being one of the last (1843). Some playgoers regretted the loss of wavering candlelight, just as some later audiences preferred the soft glow of gas to the hard brilliance of electricity. Candles, oil, and gas were all equally lethal (see FIRES IN THEATRES), but at least gas could be more easily controlled at the source, thus allowing the creation of beautiful effects of sunrise, twilight, and moonshine. Yet there were complaints that in general gas-lighting was too bright, the steady glare being fatal to the stage illusion. This was partly offset by sinking the footlights below the stage level, as planned by Fechter in 1863, and by the reforms of Irving at the Lyceum. Among other innovations, he arranged for all the lights to be regulated from the prompt corner and for the first time darkened the auditorium throughout the performance, as Ingegneri had suggested nearly 300 years earlier. Associated with the use of gas-lighting is limelight, which lived on into the age of electricity. The lime, or calcium flare, first used in 1816, gave a brilliant white light much used for ‘realistic’ beams of sun, moon, or lamp light through doors or windows. But its main use was to spotlight the chief actor and follow him about on stage, whence the expression ‘in the limelight’. Electric arc lights were in use as early as 1846 at the Paris Opéra, and were first used throughout a theatre at the Paris Hippodrome in 1878. Carbon arcs gave brilliant illumination but were noisy and apt to flicker, and limelighting continued in use in many theatres until the invention of the incandescent bulb. The first American theatre to be lit by electricity was the California in San Francisco in 1879, and the first English theatre was the Savoy in 1881. Although the Paris Opéra was not completely lit by incandescent bulbs until 1886, electricity was installed in most theatres in Europe and America by that time.

Electrification led to the development of modern stage lighting. German theatres pioneered the use of the Kuppelhorizont invented by Mariano Fortuny (1871–1949) in 1902. This ‘sky-dome’ of coloured silk reflected the beams of high-powered arcs down on to the stage, giving a bright, diffused light; it was expensive in terms of current and was replaced by the Rundhorizont, a half-dome of silk or plaster which developed into the cyclorama. Adolphe Appia and Gordon Craig did their most innovative work in Germany. They rejected the conventions of painted scenery in favour of a three-dimensional setting: the flat illumination of the late 19th-century stage had consequently to be replaced by directional lighting, casting shadows in the manner of real light to convey the mass and moulding of both actor and set. Appia insisted on the importance of lighting as an integral part of a unified artistic conception, as did Craig, who used changing lights against severely simple settings to build up an effective non-naturalistic stage picture. Special effects in the field of lighting can call on a multiplicity of techniques. Apart from imaginative colour changes, one of the simplest uses the Gobo, a cut-out mask slotted into a lantern housing to throw the shadow of leaves, architectural units, or other off-stage features on to the scene. Shadow projection, by the direct-beam projector, is a refinement of the technique introduced in 1916 by Adolph Linnebach (1876–1963) at the Court Theatre, Dresden. The Linnebach and direct-beam projectors create magical effects by means of shadowgraphs. Optical lens projectors, or stereopticons, can create up to a complete setting using large format glass slides specially painted or photographed for the purpose. Moving effects such as clouds, snow, or flames are achieved by effects projectors (sciopticons in America) carrying slides in a motor-driven turntable or drum. Such effects can be particularly successful when projected on to a gauze cloth, or unbroken stretch of fine net, in front of the action. Lighting units and dimmers have become increasingly refined and easy to operate. The spotlight, precise and economical, is the most important element in lighting, floodlighting being seldom used. Remote control was introduced in the 1930s. In the 1940s some theatres used light consoles, resembling organs, and in the 1960s lighting systems became computerized. Film projection has a place in stage production and has been used to great acclaim in the Laterna Magika of Prague, devised by Josef Svoboda, where slide and film projection are wittily combined with a few live performers to convey the illusion of a stage packed with scenery and action. Ghostly effects can be created with ultra-violet light, under which only objects coloured by fluorescent paint or dye can be seen. The pulsing flashes of strobe (stroboscopic) light can ‘freeze’ action into a series of jerks; the technique became popular due to the disco vogue and can be powerful when used with discretion. Stage lighting has achieved great subtlety in suggesting mood and scene, creating both natural and non-naturalistic effects. The lighting designer plays a vital role in the modern theatre.

lighting light produced by artificial means to allow visibility in enclosures and at night. For stage lighting, see scene design and stage lighting .

Early Sources of Artificial Lighting

The earliest means of artificial lighting were the open fire, firebrands, and torches. The first lamp was a dish of stone (later of clay, pottery, or metal) containing vegetable or animal oil and a wick. This was succeeded by the candle , first made of wax and later also of tallow, and by the lantern, which is of early origin. The Argand burner was an improved oil lamp with a burner and a chimney, and this type of lamp was widely used after the Canadian geologist Abraham Gesner popularized the use of kerosene.

The Introduction of Gas as a Fuel

Coal gas was first used as an illuminant in the late 18th cent. by the engineer William Murdock in England and by the engineer Philippe Lebon in Paris. It was used in London in 1802, in Baltimore in 1817, and in New York state in 1823. The invention of the Bunsen burner by the German chemist Robert Wilhelm Bunsen and the invention of the Welsbach mantle , a device developed by the Austrian scientist Carl von Welsbach that gives off bright light when placed over a flame, greatly stimulated the use of gas for lighting purposes.

Electric Lighting Comes of Age

The first development in electric lighting was the arc lamp, which was evolved from the carbon-arc lamp demonstrated in 1801 by Sir Humphry Davy, in which an electric current bridges a gap between two carbon rods and forms a bright discharge called an arc. Early lamps of this type were made with an open arc; later ones were enclosed in glass and thus made more practicable. Carbon-arc street lamps, first produced by the American scientist Charles F. Brush, were used in Cleveland in 1879 and soon came into wide use in other cities. The mercury-vapor electric lamp was devised by the American inventor Peter Cooper Hewitt in 1903. This type of lamp makes use of a pool of mercury liquid in a condition of high vacuum; when an electric current passes through the mercury it produces ionized vapor, which gives off a blue-green light. Modern improvements have given this lamp a much greater efficiency. The neon lamp, developed by the French physicist Georges Claude in 1911, has been largely used in commercial signs.

The Incandescent Lamp

The incandescent electric lamp, in which an electric current passing through a resistance filament (e.g., one of carbon and tungsten) enclosed in a vacuum tube heats the filament until it glows, was developed by the American electrician Moses G. Farmer in 1858-59 but was not practicable. Sir Joseph Swan in England and Thomas Edison in the United States, working independently, developed lamps of this kind; the lamp patented by Edison in 1879 was the first widely marketed incandescent lamp and was the forerunner of the modern Mazda lamp that utilizes a filament of drawn tungsten hermetically sealed in a glass envelope. A gas-filled incandescent lamp was invented by the American chemist Irving Langmuir in 1913.

The Fluorescent Lamp

The French physicist A. E. Becquerel constructed a fluorescent lamp and described (1867) the preparation of fluorescent tubes basically similar to those made today. Considerable progress in developing fluorescent lighting was made in several European countries, and during the 1920s high-voltage fluorescent tubes were used in advertising signs. In the United States the first practical hot-cathode, low-voltage fluorescent lamp was marketed in 1938. This is the form of lamp still commonly used. It consists of a long, sealed glass tube with an electrode at each end; a small amount of mercury is contained within the tube. The inside surface of the tube is coated with a mixture of fluorescent powders. When an electric current is maintained through the lamp, the mercury becomes vaporized and gives off invisible ultraviolet radiation that is absorbed by the fluorescent coating. The coating then emits visible light. The fluorescent lamp is often easily distinguished by its tubular design—straight, circular, or bent in a U or other shape. Compact fluorescent lamps, usually designed to screw into the socket originally made for an incandescent lamp, are now also shaped to resemble the less efficient incandescent lamps that they are intended to replace.

Contemporary Lighting Technology

The search for efficient artificial lighting during the 20th cent. first focused on improving incandescent lamp technology and high-intensity discharge (HID) lamps. The tungsten-halogen lamp, like the other incandescent lamps, uses a tungsten filament as the light source, a gas filling that includes a halogen , and a quartz bulb. The halogens prevent lamp walls from darkening as quickly as those of the other incandescent lamps, so more light is available to the task or work surface. HID is the term commonly used to designate four distinct types of lamps—mercury vapor, metal halide, high-pressure sodium, and low-pressure sodium—that actually have very little in common. The mercury vapor lamp produces light when the electrical current passes through a small amount of mercury vapor. The color rendering qualities of the mercury vapor lamp are not as good as those of incandescent and fluorescent lamps. The metal halide lamp is similar to the mercury vapor lamp, the major difference being that the metal halide lamp contains various metal halide additives in addition to mercury vapor. The efficiency of metal halide lamps is twice that of mercury vapor lamps. Some of the newer metal halide lamps provide color similar to that of incandescent lamps while others emulate daylight. The high-pressure sodium (HPS) lamp has the highest lamp efficiency of all lamps commonly used indoors. It produces a golden-white light when electricity passes through a sodium vapor. The low-pressure sodium (LPS) lamp, the most efficient of all, is used where color is not important because all colors illuminated by an LPS light source appear as tones of gray or yellow.

The most promising technology is that of the light-emitting diode (LED). A tiny semiconductor microchip, an LED consumes little power, is long lasting, and is relatively inexpensive. It produces visible or infrared light when subjected to an electric current. First demonstrated in 1962 and appearing in a commercial product in 1968, LEDs were limited to small applications until 1985, when more powerful LEDs were produced. Their major limitation was that only red and green microchips were possible. However, in 1993, researchers at several universities in the United States and Japan developed an LED that produced blue light that, in conjunction with the red and green chips, could produce white light; this made the LED a major player in illumination technology. Subsequently, the discovery of organic light-emitting diodes (OLEDs), made with plastics rather than silicon and other traditional semiconductor materials, opened the door for many specialty applications under the mantle of solid-state lighting.

Functional Selection of Lighting

The incandescent lamp can be considered the basic light source, because it is the one in most common use. While the least expensive to buy, it is the most expensive to own due to its low efficiency and relatively short life. The fluorescent lamp is the second most common light source. It is widely used in factories, offices, stores, and public buildings because it produces far more light for the same expenditure of electricity than do incandescent lamps. Compact fluorescent bulbs that can act as replacements for standard incandescent bulbs are sold for their long life and energy efficiency. However, to many observers the colors of objects illuminated by a fluorescent lamp often appear quite different than they would appear if the objects were illuminated by an incandescent lamp or sunlight. Sodium vapor lamps are used on some highways, as are color-corrected mercury-vapor discharge lamps. Tungsten-halogen lamps are used for lighting sports arenas and stadiums, in automobile headlights, and for residential lighting. Xenon lamps are used in flash photography as well as in cinema projectors and lighthouses.

LIGHTING

LIGHTING in America prior to about 1815 was provided by a variety of devices, including lamps fueled by oil derived from animal or vegetable sources, tallow or bayberry candles, and pinewood torches. The late eighteenth-century chemical revolution associated with Antoine Lavoisier included a theory of oxidation that soon stimulated dramatic improvements in both lamp design and candle composition. These included a lamp with a tubular wick and shaped glass chimney invented in the early 1780s by Aimé Argand, a student of Lavoisier, and introduced into the United States during the administration of George Washington. The Argand lamp was approximately ten times as efficient as previous oil lamps and was widely used in lighthouses, public buildings, and homes of the more affluent citizens. European chemists also isolated stearine, which was used in "snuffless candles," so called because they had self-consuming wicks. The candles became available during the 1820s and were produced on a mass scale in candle factories.

After European scientists discovered an efficient means of producing inflammable gas from coal, a new era of lighting began during the first decade of the nineteenth century. Baltimore became the first American city to employ gas streetlights in 1816, but the gaslight industry did not enter its rapid-growth phase until after 1850. Capital investment increased from less than $7 million in 1850 to approximately $150 million in 1880. The central generating station and distribution system that became standard in the gaslight industry served as a model for the electric light industry, which emerged during the last two decades of the century. Improvements such as the Welsbach mantle kept gas lighting competitive until World War I. Rural residents continued to rely on candles or oil lamps throughout most of the nineteenth century because coal gas could not be economically distributed in areas of low population density. The discovery of petroleum in Pennsylvania in 1859 soon led to the development of the simple and comparatively safe kerosine lamp, which continued as the most popular domestic light source in isolated areas in the United States until the mid-twentieth century.

Certain deficiencies of the gaslight, such as imperfect combustion and the danger of fire or explosion, made it seem vulnerable to such late nineteenth-century electric inventors as Thomas A. Edison. Two competing systems of electric lighting developed rapidly after the invention of large self-excited electric generators capable of producing great quantities of inexpensive electrical energy. The American engineer-entrepreneur Charles F. Brush developed an effective street-lighting system using electric arc lamps beginning in 1876. One of Brush's most important inventions was a device that prevented an entire series circuit of arc lamps from being disabled by the failure of a single lamp. Brush installed the first commercial central arc-light stations in 1879. Because of the early arc light's high intensity, it was primarily useful in street lighting or in large enclosures such as train stations.

Edison became the pioneer innovator of the incandescent-lighting industry, which successfully displaced the arc-light industry. Beginning in 1878, Edison intensively studied the gaslight industry and determined that he could develop an electric system that would provide equivalent illumination without some of the defects and at a competitive cost. His reputation attracted the financial backing needed to support research and development. Crucial to his success was the development of an efficient and long-lived high-resistance lamp, a lamp that would allow for the same necessary subdivision of light that had been achieved in gas lighting but not in arc lighting. Edison and his assistants at his Menlo Park, New Jersey, laboratory solved this problem by means of a carbon filament lamp in 1879.

Edison also proved skillful as a marketer. By 1882 his incandescent lamp system was in use on a commercial scale at the Pearl Street (New York City) generating station. All the components—not only the lamp but also the generator, distribution system, fuses, and meters—needed for an effective light-and-power system were in place.

The thirty-year period after 1880 was a time of intense market competition between the gaslight, arc light, and incandescent light industries and between the direct-current distribution system of Edison and the alternating-current system introduced by George Westinghouse. Each of the competing lighting systems made significant improvements during this period, but incandescent lighting with alternating-current distribution ultimately emerged as the leader. The General Electric Company, organized in 1892 by a consolidation of the Edison Company and the Thomson-Houston Company, became the dominant lamp manufacturer, followed by Westinghouse.

The formation of the General Electric Research Laboratory under Willis R. Whitney in 1900 proved to be an important event in the history of electric lighting. In this laboratory in 1910, William D. Coolidge invented a process for making ductile tungsten wire. The more durable and efficient tungsten filaments quickly supplanted the carbon filament lamp. Irving Langmuir, also a General Electric scientist, completed development of a gas-filled tungsten lamp in 1912. This lamp, which was less susceptible to blackening of the bulb than the older high-vacuum lamp, became available commercially in 1913 and was the last major improvement in the design of incandescent lamps.

Development of a new type of electric light began at General Electric in 1935. This was the low-voltage fluorescent lamp, which reached the market in 1938. The fluorescent lamp had several advantages over the incandescent lamp, including higher efficiency—early fluorescent bulbs produced more than twice as much light per watt as incandescent bulbs—and a larger surface area, which provided a more uniform source of illumination with less glare. It also required special fixtures and auxiliary elements. This lamp came into wide usage, especially in war factories during World War II, and then spread quickly into office buildings, schools, and stores. Homes proved much more reluctant to adopt fluorescent lighting, however, in part due to the more complicated fixtures they required and in part because incandescent bulbs produced much warmer colors. Following the energy crisis that began in 1973, designers made a number of breakthroughs that boosted the efficiency of fluorescent lamps, primarily by improving the "ballasts," which regulated the flow of energy through the bulb, and by developing new, even more efficient, compact fluorescent bulbs. Many businesses also used dimmers, timers, and motion detectors to reduce energy costs.

The energy crisis beginning in 1973 little affected the lighting habits of American homeowners, unlike its effects on American business. (Household energy costs account for only about 6 percent of the lighting energy used in the United States as compared to the roughly 50 percent used by commercial establishments.) Although some installed dimmers and timers and others paid closer attention to turning off unused lights, home consumption of energy for lighting remained relatively stable. Indeed, though energy-efficient lamps became increasingly available in the 1980s and 1990s, their gains were offset by new uses for lighting, particularly with the growth of out-door lighting in the 1990s.

BIBLIOGRAPHY

Bright, Arthur A. The Electric-Lamp Industry: Technological Change and Economic Development from 1800 to 1947. New York: Macmillan, 1949; New York: Arnco Press, 1972.

Nye, David E. Electrifying America: Social Meanings of a New Technology, 1880–1940. Cambridge, Mass.: MIT Press, 1990.

Tobey, Ronald C. Technology as Freedom: The New Deal and the Electrical Modernization of the American Home. Berkeley: University of California Press, 1996.

James E.Brittain/a. r; c. w.

See alsoElectric Power and Light Industry ; Electrification, Household ; Kerosine Oil ; Lamp, Incandescent ; Natural Gas Industry .
