Diffraction

Diffraction is the bending of waves (such as light waves or sound waves) as they pass around an obstacle or through an opening. Anyone who has watched ocean waves entering a bay or harbor has probably witnessed diffraction. As the waves strike the first point of land, they change direction. Instead of moving into the bay or harbor parallel to (in the same direction as) land, they travel at an angle to it. The narrower the opening, the more dramatic the effect. As waves enter a narrow harbor opening, such as San Francisco's Golden Gate, they change from a parallel set of wave fronts to a fan-shaped pattern.

The diffraction of light has many important applications. For example, a device known as the diffraction grating is used to break white light apart into its colored components. Patterns produced by diffraction gratings provide information about the kind of light that falls on them.

Fundamentals

All waves are subject to diffraction when they encounter an obstacle in their path. Consider the shadow of a flagpole cast by the Sun on the ground. From a distance the darkened zone of the shadow gives the

impression that light traveling in a straight line from the Sun was blocked by the pole. But careful observation of the shadow's edge will reveal that the change from dark to light is not abrupt. Instead, there is a gray area along the edge that was created by light that was bent—or diffracted—at the side of the pole.

When a source of waves, such as a lightbulb, sends a beam through an opening, or aperture, a diffraction pattern will appear on a screen placed behind the aperture. The diffraction pattern will look something like the aperture (perhaps a slit, a circle, or a square) but it will be surrounded by some diffracted waves that give it a fuzzy appearance.

The diffraction that occurs depends primarily on two variables: the wavelength of the wave and the size of the opening or aperture through which the waves pass. (Wavelength is defined as the distance between two identical parts of a wave, such as two consecutive crests of a wave. The only difference between waves of light, waves of radar, waves of X rays, and of many other kinds of waves is their wavelength—and their frequency, which depends on their wavelength.) The wavelength of light, for example, is in the range of 400 to 700 nanometers (billionths of a meter). In comparison, the wavelength of radar waves ranges from about 0.1 to 1 meter.

Words to Know

Diffraction pattern: The wave pattern observed after a wave has passed through a diffracting aperture (or opening).

Frequency: The number of segments in a wave that pass a given point every second.

Interference pattern: Alternating bands of light and dark that result from the mixing of two waves.

Wavelength: The distance between two identical parts of a wave, such as two consecutive crests of the wave.

X-ray diffraction: A method used for studying the structure of crystals.

When the wavelength of a wave is much smaller than the aperture through which it travels, the observed diffraction is small. A beam of light traveling through a window, for example, has a wavelength many trillions of times smaller than the window opening. It would be difficult to observe diffraction in this situation. But a beam of light passing through a tiny pin hole produces a different effect. In this case, a diffraction pattern can be seen quite clearly.

Applications

Diffraction gratings. A diffraction grating is a tool whose operation is based on the diffraction of light. It consists of a flat plate (usually made of glass or plastic) into which are etched thousands of thin slits or grooves. The accuracy of the grating depends on the grooves' being parallel to each other, equally spaced, and equal in width.

When light strikes a diffraction grating, it is diffracted by each of the thousands of grooves individually. The diffracted waves that are produced then mix or interfere with each other in different ways, depending on the source of the light beam. Light from a sodium vapor lamp, from a mercury (fluorescent) lamp, and from an incandescent lamp all produce different light patterns in a diffraction grating.

Scientists have recorded the kind of light pattern (spectrum) produced when each of the different chemical elements is heated and its light shined on a diffraction grating. In studying the light of an unknown object (such as a star), then, the diffraction grating spectrum can be compared to the known spectra of elements. In this way, elements in the unknown object can be identified.

X-ray diffraction. In the 1910s, William Henry (1862–1942) and William Lawrence Bragg (1890–1971), a father-and-son team of English physicists, had an interesting idea for using diffraction. They set out to find the very finest diffraction grating anyone could imagine and decided that a crystal—such as a crystal of ordinary table salt—fit the bill. The atoms and ions that make up a crystal are arranged in the same way as the grooves of a diffraction grating. Crystalline atoms and ions are laid out in very orderly rows at exactly the same distance from each other, as is the case with a diffraction grating. But the size of the "grooves" in a crystal (the space between atoms and ions) is much smaller than in any human-made diffraction grating.

The Braggs set to work experimenting with crystals and diffraction. Unfortunately, the wavelength of a light wave was too large to be diffracted by atoms and ions in a crystal. But X rays—which have a much smaller wavelength than light waves—would diffract perfectly off rows of atoms or ions in a crystal.

When the Braggs shined X rays off various crystals, they made a fascinating discovery. For each type of crystal studied, a unique pattern of fuzzy circles was produced. X rays had been diffracted according to the ways in which atoms or ions were arranged in the crystal. The Braggs had discovered a method for determining how atoms or ions are arranged in a given crystal. That method, known as X-ray crystallography, is now one of the most powerful tools available to chemists for analyzing the structure of substances.

[See also Hologram and holography; Wave motion ]

diffraction bending of waves around the edge of an obstacle. When light strikes an opaque body, for instance, a shadow forms on the side of the body that is shielded from the light source. Ordinarily light travels in straight lines through a uniform, transparent medium, but those light waves that just pass the edges of the opaque body are bent, or deflected. This diffraction produces a fuzzy border region between the shadow area and the lighted area. Upon close examination it can be seen that this border region is actually a series of alternate dark and light lines extending both slightly into the shadow area and slightly into the lighted area. If the observer looks for these patterns, he will find that they are not always sharp. However a sharp pattern can be produced if a single, distant light source, or a point light source, is used to cast a shadow behind an opaque body. Diffraction also occurs when light waves interact with a device called a diffraction grating. A diffraction grating may be either a transmission grating (a plate pierced with small, parallel, evenly spaced slits through which light passes) or a reflection grating (a plate of metal or glass that reflects light from polished strips between parallel lines ruled on its surface). In the case of a reflection grating, the smooth surfaces between the lines act as narrow slits. The number of these slits or lines is often 12,000 or more to the centimeter (30,000 to the inch). The ruling is generally done with a fine diamond point. Since the light diffracted is also dispersed (see spectrum ), these gratings are utilized in diffraction spectroscopes for producing and analyzing spectra and for measuring directly the wavelengths of lines appearing in certain spectra. The diffraction of X rays by crystals is used to examine the atomic and molecular structure of these crystals. Beams of particles can also exhibit diffraction since, according to the quantum theory , a moving particle also has certain wavelike properties. Both electron diffraction and neutron diffraction have been important in modern physics research. Sound waves and water waves also undergo diffraction.

diffraction The slight bending of light around the edge of an obstacle in its path. It is a consequence of the wave nature of light. Because of diffraction, a star image consists of an Airy disk surrounded by several diffraction rings, produced by diffraction at the edge of the telescope lens or mirror. In a reflecting telescope which has a secondary mirror supported by one or more arms, diffraction around the arms causes the images of stars to have spikes. Diffraction also occurs at other wavelengths, such as radio. A point radio source occulted by the Moon, for example, disappears or reappears with brightness oscillations, rather than abruptly, as a diffraction pattern sweeps across the observatory. The size of the diffraction pattern increases with the wavelength of the radiation involved.

diffraction The radial scattering of any wave (light, radio, seismic, water, etc.) incident upon an abrupt discontinuity in accordance with Huygens' principle. A fault plane, angular unconformity, small isolated objects (e.g. boulders, fragments of wrecked ships, etc.) will all give rise to the diffraction of incident seismic energy. The quasi-hyperbolic curvature of a seismic diffraction event is related to the velocity within the media through which the diffracted wave travels. In media with slow velocities, the hyperbola is strongly curved, the curvature decreasing as velocity increases.

diffraction Spreading of a wave, such as a light beam, on passing through a narrow opening or hitting an obstacle, such as sound being heard around corners. It is evidence for the wave nature of light. Diffraction provides information on the wavelength of light and the structure of crystals.

dif·frac·tion / diˈfrakshən/ • n. the process by which a beam of light or other system of waves is spread out as a result of passing through a narrow aperture or across an edge, typically accompanied by interference between the wave forms produced.

diffraction XVII. F. diffraction or modL. diffractio, f. diffract-, pp. stem of L. diffringere break in pieces, f. DIF- + frangere BREAK 1.
