brake

brake

The Columbia Encyclopedia, 6th ed. | 2008 | Copyright

brake in technology, device to slow or stop the motion of a mechanism or vehicle.

Types

Friction Brakes

Friction brakes, the most common kind, operate on the principle that friction can be used to convert the mechanical energy of a moving object into heat energy, which is absorbed by the brake. The essential components of a friction brake are a rotating part, such as a wheel, axle, disk, or brake drum, and a stationary part that is pressed against the rotating part to slow or stop it. The stationary part usually has a lining, called a brake lining, that can generate a great amount of friction yet give long wear; it formerly contained asbestos , but this is being replaced by less efficient materials for environmental reasons.

The principal types of friction brake are the block brake, the band brake, the internal-shoe brake, and the disk brake. The block brake consists of a block, the stationary part, that is shaped to fit the contour of a wheel or drum. For example, a wooden block applied to the rim of a wheel has long been used to slow or stop horse-drawn vehicles. A simple band brake consists of a metal band, the stationary part, that can be tightened around a drum by means of a lever. It is found on hoists and excavating machinery. The internal-shoe brake has a drum that contains two stationary semicircular pieces, or shoes, which slow or stop the motion of the drum by pressing against its inner surface. This is the type of brake most often found on automobiles, with an internal-shoe brake drum located on the central part of each wheel. A disk brake of the type used on automobiles has a metal disk and pistons with friction pads that can close on the disk and slow it.

Electric Brakes

A machine that is driven by an electric motor can sometimes use its motor as a brake. Because inertia keeps the machine's shafts moving after the current to the electric motor has been shut off, the machine keeps the motor's armature turning. While this is happening, if the motor's action can be changed to that of a generator, the electric current produced will be drawing its energy from the machine, thus slowing it. However, since such a braking method is not suitable for bringing the machine to a quick stop, it is usually supplemented by friction brakes.

Braking Systems

A manually operated brake pedal or handle is used to activate a brake. With low-power machinery or vehicles the operator can usually apply sufficient force through a simple mechanical linkage from the pedal or handle to the stationary part of the brake. In many cases, however, this force must be multiplied by using an elaborate braking system.

The Air Brake System

An early system for multiplying the braking force, called the air brake system, or air brake, was invented by American manufacturer George Westinghouse and was first used on passenger trains in 1868. It is now widely used on railroad trains. The fundamental principle involved is the use of compressed air acting through a piston in a cylinder to set block brakes on the wheels. The action is simultaneous on the wheels of all the cars in the train. The compressed air is carried through a strong hose from car to car with couplings between cars; its release to all the separate block brake units, at the same time, is controlled by the engineer. An automatic feature provides for the setting of all the block brakes in the event of damage to the brake hose, leakage, or damage to individual brake units. The air brake is used also on subway trains, trolley cars, buses, and trucks.

The Hydraulic Brake System

The hydraulic brake system, or hydraulic brake, is used on almost all automobiles (see hydraulic machine ). When the brake pedal of an automobile is depressed, a force is applied to a piston in a master cylinder. The piston forces hydraulic fluid through metal tubing into a cylinder in each wheel where the fluid's pressure moves two pistons that press the brake shoes against the drum.

The Vacuum Brake System

The vacuum brake system, or vacuum brake, depends upon the use of a vacuum to force a piston in a cylinder to hold a brake shoe off a drum; when the vacuum is destroyed, the shoe is released and presses on the drum. In an automotive power brake system, extra pressure can be exerted on the hydraulic master cylinder piston by a vacuum brake's piston.

Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1E1-brake-tec.html

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1E1-brake-tec.html

Learn more about citation styles

brake

The Oxford Pocket Dictionary of Current English | 2009 | Copyright

brake1 / brāk/ • n. a device for slowing or stopping a moving vehicle, typically by applying pressure to the wheels: he slammed on his brakes. ∎  a thing that slows or hinders a process: China's decision to put the brakes on economic reform. • v. [intr.] make a moving vehicle slow down or stop by using a brake: drivers who brake abruptly [as adj.] (braking) an anti-lock braking system. brake2 • n. hist. an open, horse-drawn, four-wheeled carriage. brake3 • n. a toothed instrument used for crushing flax and hemp. ∎  (also brake harrow) a heavy machine formerly used in agriculture for breaking up large lumps of earth. brake4 • n. archaic or poetic/lit. a thicket. See also canebrake, fernbrake. brake2 (also brake fern) • n. a coarse fern (genus Pteris, family Pteridaceae) of warm and tropical countries, frequently having the fronds divided into long linear segments. ∎  archaic term for bracken. brake3 • archaic past of break.

Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." The Oxford Pocket Dictionary of Current English. 2009. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." The Oxford Pocket Dictionary of Current English. 2009. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O999-brake.html

"brake." The Oxford Pocket Dictionary of Current English. 2009. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O999-brake.html

Learn more about citation styles

brake

World Encyclopedia | 2005 | Copyright

brake Device for slowing the speed of a vehicle or machine. Braking can be accomplished by a mechanical, hydraulic (liquid), or pneumatic (air) system that presses a non-rotating part into contact with a rotating part, so that friction stops the motion. In a car, the non-rotating part is called a shoe or pad, and the rotating part is a disc or drum attached to a wheel. Some vehicles use electromagnetic effects to oppose the motion and cause braking. A ‘power’ brake utilizes a vacuum system.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." World Encyclopedia. 2005. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." World Encyclopedia. 2005. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O142-brake.html

"brake." World Encyclopedia. 2005. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O142-brake.html

Learn more about citation styles

brake

The Oxford Companion to Ships and the Sea | 2006 | Copyright

brake, the handle or lever by which the common ship's pump was worked before the days of auxiliary machinery. In ships of any size the pump was manned by up to six men working on the brake in short spells.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." The Oxford Companion to Ships and the Sea. 2006. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." The Oxford Companion to Ships and the Sea. 2006. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O225-brake.html

"brake." The Oxford Companion to Ships and the Sea. 2006. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O225-brake.html

Learn more about citation styles

brake

The Concise Oxford Dictionary of English Etymology | 1996 | | Copyright

brake1 thicket. OE. bracu, corr. to MLG. brake branch, etc.; prob. f. *brak- *brek- BREAK1, the orig. sense being ‘broken wood’ perh. reinforced in ME, from LG.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O27-brake.html

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O27-brake.html

Learn more about citation styles

brake

The Concise Oxford Dictionary of English Etymology | 1996 | | Copyright

brake3 apparatus for retarding the motion of a wheel. XVIII. prob. spec. use of †brake bridle, curb (XV-XVIII) — MDu. braeke, rel. to breken BREAK1.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O27-brake2.html

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O27-brake2.html

Learn more about citation styles

Brake

Dictionary of Collective Nouns and Group Terms | 1985 | Copyright

Brake

a clump of brushes, brushwood, or briars. See also thicket.

Example: brakes of fern, shrub, and fallen trees, 1772.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"Brake." Dictionary of Collective Nouns and Group Terms. 1985. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"Brake." Dictionary of Collective Nouns and Group Terms. 1985. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1G2-2505300163.html

"Brake." Dictionary of Collective Nouns and Group Terms. 1985. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1G2-2505300163.html

Learn more about citation styles

brake

The Concise Oxford Dictionary of English Etymology | 1996 | | Copyright

brake2 fern, bracken. XIV. perh. shortening of BRACKEN, through the apprehension of this as a pl. form.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O27-brake1.html

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O27-brake1.html

Learn more about citation styles

brake

A Dictionary of Ecology | 2004 | | Copyright

brake An area of bracken (or other fern), scrub, or underwood.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

MICHAEL ALLABY. "brake." A Dictionary of Ecology. 2004. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

MICHAEL ALLABY. "brake." A Dictionary of Ecology. 2004. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O14-brake.html

MICHAEL ALLABY. "brake." A Dictionary of Ecology. 2004. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O14-brake.html

Learn more about citation styles

brake

A Dictionary of Plant Sciences | 1998 | | Copyright

brake An area of bracken (or other fern), scrub, or underwood.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

MICHAEL ALLABY. "brake." A Dictionary of Plant Sciences. 1998. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

MICHAEL ALLABY. "brake." A Dictionary of Plant Sciences. 1998. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O7-brake.html

MICHAEL ALLABY. "brake." A Dictionary of Plant Sciences. 1998. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O7-brake.html

Learn more about citation styles

brake

The Columbia Encyclopedia, 6th ed. | 2008 | Copyright

brake in botany: see bracken .

Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1E1-X-brake-bot.html

"brake." The Columbia Encyclopedia, 6th ed.. 2008. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1E1-X-brake-bot.html

Learn more about citation styles

brake

The Concise Oxford Dictionary of English Etymology | 1996 | | Copyright

brake4 see BREAK2.
Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O27-brake3.html

T. F. HOAD. "brake." The Concise Oxford Dictionary of English Etymology. 1996. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O27-brake3.html

Learn more about citation styles

brake

Oxford Dictionary of Rhymes | 2007 | Copyright

brake •ache, awake, bake, betake, Blake, brake, break, cake, crake, drake, fake, flake, forsake, hake, Jake, lake, make, mistake, opaque, partake, quake, rake, sake, shake, sheikh, slake, snake, splake, stake, steak, strake, take, undertake, wake, wideawake •bellyache • clambake • headache •backache • pancake • teacake •seedcake • beefcake • cheesecake •fishcake • johnnycake • tipsy cake •rock cake • shortcake • oatcake •oilcake • fruitcake • cupcake •pat-a-cake • cornflake • snowflake •rattlesnake • handbrake • mandrake •heartbreak • airbrake • daybreak •jailbreak • canebrake • windbreak •tiebreak • corncrake • outbreak •footbrake • muckrake • earache •firebreak • namesake • keepsake •handshake • milkshake • heartache •beefsteak • sweepstake • stocktake •out-take • uptake • grubstake •wapentake • toothache • seaquake •kittiwake • moonquake • earthquake

Show all research tools

Cite this article
Pick a style below, and copy the text for your bibliography.

  • MLA
  • Chicago
  • APA

"brake." Oxford Dictionary of Rhymes. 2007. Encyclopedia.com. 10 Feb. 2012 <http://www.encyclopedia.com>.

"brake." Oxford Dictionary of Rhymes. 2007. Encyclopedia.com. (February 10, 2012). http://www.encyclopedia.com/doc/1O233-brake.html

"brake." Oxford Dictionary of Rhymes. 2007. Retrieved February 10, 2012 from Encyclopedia.com: http://www.encyclopedia.com/doc/1O233-brake.html

Learn more about citation styles
