Harp

Background

A harp is a musical instrument consisting of a triangular frame open on both sides which contains a series of strings of varying lengths that are played by plucking. The length of the string determines how high or low a sound it makes. A modern concert harp stands about 70-75 in (1.8-1.9 m) high, is about 40 in (1 m) wide, weighs about 70-90 lb (32-41 kg), and has 47 strings, ranging in size from a few inches to several feet in length.

Smaller instruments similar to the harp include the lyre, which has strings of the same length but of varying thickness and tension; the psaltery, which has a frame open only on one side; and the dulcimer, which is similar to the psaltery but which is played by striking the strings with a hammer rather than plucking them.

History

The earliest harps probably developed from hunting bows and consisted of a few strings attached to the ends of a curved wooden body. A harp used in Egypt about five thousand years ago consisted of six strings attached to this kind of body with small wooden pegs. By 2500 b.c., the Greeks used large harps, consisting of strings attached to two straight pieces of wood which met at an angle.

By the ninth century, frame harps, which enclosed wire strings within a triangular wooden frame, appeared in Europe. They were fairly small [2-4 ft (0.6-1.2 meters) high] and were used by traveling musicians, particularly in Celtic societies. Many performers of traditional music (who are usually known as harpers rather than harpists) still use this type of instrument today.

The inability of these harps to play accidentals (notes a half-tone higher or lower than the notes of the scale to which the strings were tuned) led to a number of experiments. Harps were built with extra strings to play accidentals, either by increasing the number of strings in a single row or by adding a second row of strings parallel to the first to form double strung harps. In Wales, some harps had three rows of strings.

Instead of increasing the number of strings, some harpmakers devised mechanisms for changing the length of the strings, thereby adjusting the pitch. By the end of the seventeenth century, hooks were used in the Tyrol region of Austria to shorten strings as needed, providing two notes from each string. In 1720, Celestin Hochbrucker added seven pedals to control these hooks. In 1750, Georges Cousineau replaced the hooks with pairs of metal plates and doubled the number of pedals to produce three notes per string.

In 1792, Sébastien Érard replaced the metal plates with rotating brass disks bearing two studs, each of which gripped the string like a fork when the disk turned. He also reduced the number of pedals back to seven by devising pedals which could occupy three different positions each. Érard's design is still used in modern concert harps today. In the late nineteenth century and throughout the twentieth century, innovations were made in harpmaking by the American harp manufacturing company Lyon and Healy. These innovations included redesigning the stave back and the sound chamber of the harp.

Raw Materials

A harp is basically a large wooden triangle, usually made primarily of maple. The front, vertical side of the triangle is known as the column or the forepillar. The upper, curved side of the triangle is known as the neck. The third side of the triangle is known as the body. White maple is the best wood for these three sides because it is strong enough to withstand the stress of the strings. The soundboard, which is contained within the body and which amplifies the sound of the strings, is usually made of spruce. Spruce is used because it is light, strong, pliable, and evenly-grained, enabling it to respond uniformly to the vibrations of the strings to produce a rich, clear sound. The middle of the soundboard, known as the centerstrip, is attached to the base of the strings and is usually made of beech. Beech is used because it is tough enough to bear the tension of the strings.

The curved plate on the neck of the harp, to which the strings are attached, is made of brass. The disks which control the length of the strings are also brass, as are the pedals which control the disks. These external metal parts are often plated with gold for appearance and to resist tarnishing. The complex internal mechanism which connects the pedals to the disks, known as the action, is made of brass and stainless steel, with some parts such as washers made of a hard plastic such as nylon.

The strings of a harp are made of a variety of materials, including steel, gut (derived from the intestines of sheep), and nylon. Each material has different properties which make it suitable for a particular length of string.

The surface of a harp may be treated with clear lacquers or wood stains of various colors such as ebony or mahogany. It may also be inlaid with decorative woods such as walnut or avodire (a pale yellow West African wood). Some harps are gilded with 23 karat gold leaf. The soundboard may be decorated with paint or gold decals.

Design

Each harp is a unique work of art. The design of the harp depends on the needs of the performer. Traditional harpers require small, light instruments with strings controlled by levers. Classical harpists require much larger instruments with strings controlled by pedals. The exterior design of harps varies from simple curves with natural finishes to intricate carvings with a wide variety of decorations ranging from abstract geometric designs to romantic floral displays.

The Manufacturing
Process

Making the wooden components

• 1 Boards of spruce, maple, beech, and other woods are received by the harpmaker and inspected. In order to perfectly match the grain of harp with a natural finish, boards of wood all from the same tree may be received together. The boards are then stored for about six months to become adjusted to the local climate in order to avoid any future problems with splitting or cracking.
• 2 Power woodcutting machines cut the boards into rough approximations of the pieces needed. More detailed shaping of these pieces is done with hand held woodcutting tools. Harpmakers learn their craft in a series of apprenticeships. New workers build the base of the harp, then go on to learn the skills needed to build the body and the soundboard. Only the most experienced harpmakers work on the column and the neck. Many thin layers of wood are glued together under pressure to foim wooden parts which are stronger than solid wood. The various wooden parts are then stored to await assembly.

Making the metal components

• 3 Metalworkers use a wide variety of power and hand held tools to shape brass and steel into the nearly 1,500 pieces needed to make up the action of the harp. Some simple parts may be purchased from outside manufacturers. The metal components are then stored to await assembly.

Decorating the wooden components

• 4 Before assembly the wooden components are decorated as desired. The column may be hand carved with complex designs which take several weeks to complete. All wooden parts are sanded smooth in preparation for finishing. They are then sprayed with clear lacquer or colored wood stain. After one coat of lacquer or stain is applied, it is allowed to dry and then sanded smooth again. This process is repeated up to 10 times over as long as two weeks. The soundboard may then be painted with elaborate designs.
• 5 Some harps have gilded columns and bases. The gilder begins by sanding unfinished wooden parts to remove all imperfections. Layers of gesso (a special mixture of glues) are applied to the smooth wood. After the gesso sets, layers of clay are applied and sanded smooth. Glue is applied to a small area of the smooth clay. Gold leaf 0.000004 inches thick (0.1 microns) is applied with a brush. (The gold is so thin that it cannot be handled directly by human hands.) The process is repeated on other small areas until an entire component is gilded. Excess gold is wiped away and another layer of gold leaf is applied. Some portions of the gold are burnished to a brilliant sheen by rubbing them with a tool made of polished agate. Clear lacquer is applied to protect the gold.

Assembling the harp

• 6 Master harpmakers begin the slow, painstaking process of bringing the wood and metal components together to form the harp. The parts of the neck, body, soundboard, base, and column are brought together to form the frame. The complex mechanism of the action is fitted within the column and connected to the disks on the brass plate below the neck and the pedals on the base. Strings are attached to brass pegs on the neck, fed through the disks, and attached to the centerstrip of the soundboard. At first the strings are very loose. They are slowly tightened to the correct level of tension and tuned to the correct pitch.
• 7 After a final inspection, the harp is packed in close-fitting foam within a cardboard box to be shipped to the purchaser. The harp manufacturer also makes special protective wooden cases with wheels which allow the harp to be moved with relative ease.

Quality Control

Every step in the harpmaking process requires extreme attention to quality. Lumber is inspected for flaws. In particular, the spruce used for the soundboard is tested for its acoustic properties to ensure the quality of the sound it will produce. Each wooden component is individually inspected by a master harpmaker, then again after it has been sanded smooth for finishing. Metal components are also individually inspected. Those purchased from outside companies are inspected to ensure that they match the blueprints supplied by the harpmaker.

The strings are carefully tuned during the assembly process by an expert tuner. The action is tested to ensure that it is silent to avoid interfering with the music. The approximately 400 holes in the brass plate which holds the disks may be drilled by computer-controlled equipment to ensure accurate alignment. The harpmaker may choose to have a professional musician test each completed harp to ensure the quality of its sound.

The Future

Two seemingly contradictory trends hint at the future of the harp industry. Sparked by an increasing interest in Celtic music, more musicians are using harps similar to those used 1,000 years ago. On the other hand, many rock and jazz musicians are tuming to electric harps, which produce amplified sounds in a manner similar to electric guitars. Despite these trends, it seems likely that harps similar to those designed by Sebastien trard will continue to dominate the industry.

Where to Learn More

Books

Gammond, Peter. Musical Instruments in Color. Macmillan, 1976.

Rensch, Rosalyn. Harps and Harpists. Indiana University Press, 1989.

Other

Lyon and Healy. http://www.lyonhealy.com (July 9, 1997).

Strohmer, Shaun. "What Makes a Harp a Harp." http://harp.column.com/feature.html (September 25, 1996).

—RoseSecrest

harp. This instr., of very ancient lineage, can be simply defined as an open frame over which is stretched a graduated series of str., set in vibration by plucking with the fingers. In the modern orch. hp. the series is not normally chromatic, as it is in the pf., having merely 7 different notes with the octave, these being in the major scale of B (treated for convenience as that of C♭). There are 7 pedals, each affecting one note of this foundational scale; each pedal works to 2 notches, and by depressing it to its first or 2nd notch, respectively, the vibrating lengths of all the relevant strings are simultaneously shortened by fractions representing a semitone and a tone: thus all keys become possible, and by depressing all the pedals together the pitch of the complete instr. can be raised from C♭ (the normal key) to C♮ or C♯. The usual compass is 5 ½ octaves from C. Chords are normally played in more or less rapid succession of their notes, in the form understood by the word arpeggio (It. arpa, hp.). The typical ‘sweeping’ (glissando) action of the hand may be used in many kinds of scale (but evidently not in the chromatic scale, nor in any other scale passage employing more than 8 notes to the octave). In addition, of course, single str. may be plucked individually or in small groups. The instr. described above is the double-action hp., introduced by Érard (c.1810), the word ‘double’ marking its differences from its predecessors on which the pitches could be raised only a semitone.

One earlier form of the hp. is the Welsh harp or telyn, with 3 rows of str., the 2 outer rows (tuned in unison or octaves) giving the diatonic scale and the inner row the intermediate semitones: a simple modulation was effected by touching one of the inner str.

The hp. has been much used as a solo instr. in Wales from time immemorial and in Eng. domestically during the Victorian period. It was a frequent member of the early 17th-cent. orch. but in later times was rarely found again in orch. use until the 19th cent. when the great Romantic orchestrators—Berlioz, Wagner, Strauss, Mahler, Elgar, etc.—made effective use of it. In the 20th cent. it has been used in chamber mus. (e.g. by Debussy and Ravel). There are several hp. concs.

See also chromatic harp, double harp, clàrsach, dital harp, aeolian harp.

harp stringed musical instrument of ancient origin, the strings of which are plucked with the fingers. Harps were found in paintings from the 13th cent. BC at Thebes. In different forms it was played by peoples of nearly all lands throughout the ages. The harp was particularly popular with the Irish from the 9th cent. They adopted the small instrument still in use, called the Irish harp, as a national symbol. The larger instrument was well known on the Continent by the 12th cent. During the 15th cent. the harp came to be made in three parts, as it is today: sound box, neck, and pillar. The strings are stretched between the sound box and the neck; into the neck are fastened the tuning pegs. Chromatic harps, having a string for each tone of the chromatic scale, have appeared since the late 16th cent., but none has been as practical as the diatonic harp, made in the late 17th cent. in the Tyrol and equipped with hooks capable of altering the pitch of any string by a semitone. A pedal mechanism that shortened the strings was devised (c.1720) in Germany. The harp was perfected with Sébastien Érard's invention (c.1810) of the double-action pedals, which can shorten each string twice, raising the pitch by a semitone or a tone. The harp appeared occasionally in the orchestra in the 18th cent., but its regular inclusion there, as well as most of its solo literature, dates from the late 19th cent.

Bibliography: See R. Rensch, The Harp (1970) and Harps and Harpists (1989).

harp / härp/ • n. 1. a musical instrument, roughly triangular in shape, consisting of a frame supporting a graduated series of parallel strings, played by plucking with the fingers. The modern orchestral harp has an upright frame, with pedals that enable the strings to be retuned to different keys. 2. inf. short for harmonica. • v. [intr.] 1. talk or write persistently and tediously on a particular topic. 2. archaic play on a harp.

harp

harp The Hebrews had a family of stringed instruments under the general category of harp. They included psalteries, lyres, lutes, and dulcimers. The psaltery was triangular in shape; the lyre was U-shaped. There is also a similar instrument translated ‘sackbut’ (Dan. 3: 5, AV)—trigon in NRSV, triangle in REB, zither in NJB—which had strings plucked either by the fingers or by a plectrum.

harp Ancient musical instrument consisting of a frame over which strings are stretched. Variations have been found in civilizations as diverse as Egyptian, Greek and Celtic. A modern orchestral harp has a large triangular frame that carries 47 strings. Seven pedals ensure the whole chromatic range is covered by altering the pitch of the strings.

harp sb. OE. hearpe = OS. harpa (Du. harp), OHG. harfa (G. harfe), ON. harpa :- Gmc. *χarpōn.
So vb. OE. hearpian.

harp •Arp, carp, harp, scarp, sharp, tarp •cardsharp
