Ionic order

Ionic order , one of the early orders of architecture . The spreading scroll-shaped capital is the distinctive feature of the Ionic order; it was primarily a product of Asia Minor, where early embryonic forms of this capital have been found. In the Ionian colonies of Greece on the southwestern shores of Asia Minor, the Ionic order had attained a full development in the 6th cent. BC In the 5th cent. BC it appeared in Greece proper, where the Erechtheum embodies the one really complete example. Greek Ionic columns are of slender proportion, their height being generally about nine times the column's lower diameter; the order is always used with a base. A column shaft with 24 flutings seems to have been the most developed form. The spiral scrolls, or volutes, at either side of the cap run from front to rear, and an echinus molding with egg-and-dart ornamentation occupies the space between them. The entablature, usually about one quarter the height of the column, has an architrave generally divided into three bands, each projecting beyond the next; a frieze, often adorned with sculpture; and a cornice enriched with dentils, above which are a corona and a crowning cyma molding. A late and vigorously monumental development of the order took place in the Hellenistic temples of Asia Minor at the middle of the 4th cent. BC In employing this order the Romans used details that were not as fine. The temple of Saturn shows a variation of the four-cornered Ionic cap, which had been created in Greece for the corner columns of a portico. A cap of this type, with corner volutes, was developed by the Italian Renaissance architect Scamozzi into a design bearing his name; variations of it were widely used during the Renaissance and in subsequent periods, particularly the baroque. For the other Greek orders see Doric order ; Corinthian order .

ionic order One of the classical orders of architecture

Ionic Order. Classical Order of architecture, the second Greek and the third Roman. It is primarily identified by its capital, with its rolled-up cushion-like form on either side creating the distinctive volutes. The Ionic Order has a base of the Asiatic or Attic type (the latter being favoured by the Romans), and the shaft is more slender in proportion than in the Doric Order: Greek shafts are almost invariably fluted with fillets separating the flutes (although Hellenistic columns often have the lower part of the shaft faceted or plain, as in the stoa, Priene (c.158–156 bc)), but Roman shafts are often wholly unfluted. The astragal, echinus, and fillet occur in both Greek and Roman capitals, the echinus is enriched with egg-and-dart, and sometimes (e.g. Erechtheion, Athens) the astragal is embellished with bead-and-reel. The particularly elegant and beautiful capitals of the Erechtheion (c.421–407 bc) also have a hypotrachelion enriched with a continuous frieze of anthemion motifs, while the astragal below has bead-and-reel and the moulded abacus is ornamented with egg-and-dart. Indeed, abaci are always moulded, much smaller than Doric abaci, and usually plain, but sometimes enriched. Entablatures consist of architrave (usually divided into fasciae), frieze (sometimes omitted, particularly in Hellenistic buildings), and cornice. The frieze has no metopes or triglyphs, so the inter-columniation discipline inherent in Doric does not exist, and spacing can be wider. Furthermore, the Ionic frieze may be a plain band, can be richly ornamented with continuous sculpture either in relief (as with Roman work), or as applied in different coloured stone (e.g. Erechtheion), and may also be pulvinated (as in the thermae of Diocletian, Rome). Cornice-mouldings can be very rich, with bed-mouldings including dentil-courses, egg-and-dart, or other ornament, as in the temple of Fortuna Virilis, Rome (c.40 bc). Additional mouldings of bead-and-reel occur between the architrave fasciae in richer versions of the Order. One of the main problems when using the Ionic Order is the capital, with its two distinct elevations—one with the two volutes (desirable on a front), and the ‘side’ with the baluster side or pulvinus (not desirable on a façade). In Greek temples, therefore, a ‘special’ had to be designed so that two adjacent volutes would appear on two faces at the external angle of a portico by pulling the corner volutes out with concave curved faces at 45° (135° to each façade). This angle-capital also had two adjacent partial volutes at the inner angle within the portico. This some-what clumsy arrangement was superseded by the Romans, who invented a capital with four identical faces, the eight volutes projecting under the four corners of the abacus thus doing away with the need for a ‘special’ as all the capitals were the same on all four sides. This angular capital (also known as the Scamozzi Order) was used at the temple of Saturn, Rome (c.42 bc, rebuilt c. ad 320), and was the basis for the upper part of the Composite capital. See also Ammonite.

Bibliography

J. Curl (2001);
Dinsmoor (1950);
C. Normand (1852)
